Pilot-scale Fully Automatic Stainless Steel Fermentation Equipment
Summary: Designed for process scale-up and pilot testing, this system uses 304/316 stainless steel and features an integrated automated control system that supports fermentation environments simulating production conditions. Suitable for microbial fermentation process optimization and production, the structure and functions can be customized to meet specific needs.
Product Details
Product Introduction
Designed for process scale-up and pilot testing, using 304/316 stainless steel material, integrated with an automated control system, supporting fermentation environments that simulate production conditions. Suitable for process optimization and production of microbial fermentation, structure and functions can be customized according to needs.
Product Features
• Automated Control: Real-time monitoring and adjustment of parameters such as temperature, pH, and dissolved oxygen; data is traceable and supports process reproduction.
• Hygienic Material: 316L stainless steel body, easy to clean, and corrosion-resistant.
• Multi-Tank Design: Multiple levels of fermentation can be set, supporting the cultivation of multiple strains and adapting to diverse production needs.
• Flexible Expansion: Modular design, facilitating functional upgrades and scale adjustments.
• Optimized Mixing System: Customized stirring structure, improving mixing uniformity.
Product Parameters
| Model | MKY-ATZ | Tank Material | Body 316L/Jacket 304 |
| Volume | 20L~5000L | Stirring Method | Mechanical Stirring/Magnetic Stirring |
| Filling Factor | 40-75% | Drive Type | Servo Driver/Inverter |
| Sealing Method | Mechanical Seal | Sterilization Method | In-situ Sterilization |
| Control Method | PLC+Touch Screen, Fully Automatic Control/Automatic Fermentation Process Control | ||
| Basic Configuration | Temperature, PH, Dissolved Oxygen, Antifoam, Feeding, Speed, Airflow, Sterilization, Tank Pressure, Air Intake Filtration | ||
| Optional Configuration | OD, ORP, Conductivity, Level Control, Tank Weighing, Feeding Weighing System, Multi-channel Gas, Multi-channel Feeding, Exhaust Gas Analysis, etc. | ||
